Heatsinks
Heatpipe Assembly 001
What is Heat pipe Assembly heat sink?
Skived Fin 001
What is skived Fin heat sink?
Extrusion001
What is Profile heat sink?
Extrusion 002
Heatpipe Assembly 002
The Working principle principle of heat pipes
Skived Fin 002
The principle of Skived fin forming
Key points of profile heat sinks design
The principle of extrusion molding
Extrusion 003
Heatpipe Assembly 003
Characteristics of Heat pipe Assembly heat sinks
Skived Fin 003
Characteristics of Skived fin heat sink
Characteristics of aluminum extruded heat sinks
Extrusion 004
Heatpipe Assembly 004
Key points of Heat pipe Assembly heat sinks design
Skived Fin 004
Key points of profile heat sinks design
Extrusion 005
Heatpipe Assembly 005
Economic considerations
Skived Fin 005
Economic considerations
Economic considerations
  • Typ

  • Heatpipe Assembly Heat sink

  • Process

  • Bending/Flattening/Brazing

  • Extra Process

  • Extrusion/Skiving+CNC Machining

  • Material

  • Al1060、 Al 6061、Al6063、Cu1100、Cu1020

  • Size/Color

  • customized

  • Surface  treatment

  • Sandblasting, Wire Drawing, Painting, Electroplating, Anodizing

  • Quality Control

  • full inspection

  • Application

  • Mechanical Equipment、Source、Electronic Devices

  • OEM

  • Accept


A Heat pipe Assembly heat sink is a heat dissipation device that applies the principle of heat pipes, generally composed of a heat dissipation substrate, heat pipes, and heat sinks welded together. It can solve the heat dissipation problem caused by limited space or excessive heat concentration, and overcome the contradiction between heating power and effective heat dissipation capacity that traditional heat dissipation modes cannot overcome..


  • Type

  • Skived Fin Heat sink

  • Process

  • Skiving

  • Extra Process

  • Skiving+CNC Machining

  • Material

  • AL1060、AL 6061、AL6063、Cu1100、Cu1020

  • Size/Color

  • customized

  • Surface  treatment

  • Sandblasting, Wire Drawing, Painting, Electroplating, Anodizing

  • Quality Control

  • full inspection

  • Application

  • Automobile、Inverter、Communication

  • OEM

  • Accept


The skived Fin heat sink is a type of heat sink that is constructed from a single piece metal material. It gives a reduced thermal resistance since there is no joint connecting the base and the fins. Since it allows for a high fin density and offers a thin finned heat sink, Skived Fin heat sink provides highly optimized cooling capabilities.


  • Type

  • Extrusion Heat sink

  • Process

  • Extrusion

  • Extra Process

  • Extrusion+CNC Machining

  • Material

  • AL 6061、AL6063

  • Size/Color

  • customized

  • Surface  treatment

  • Sandblasting, Wire Drawing, Painting, Electroplating, Anodizing

  • Quality Control

  • full inspection

  • Application

  • Mechanical Equipment、Source、Electronic Devices

  • OEM

  • Accept


Profile is a material used for heat conduction and dissipation. It is made into the desired shape through extrusion technology, after further processing, such as cutting, precision machining, and surface treatment, finally made into a profile heat sink. Aluminum profile heat sinks are widely used in various industries for thermal and heat dissipation scenarios.


  • Type

  • Copper Tube cold plates

  • Process

  • buried pipe, welded pipe, double-sided clamp pipe

  • Extra Process

  • Brazing+CNC Machining

  • Material

  • AL 6061、AL6063、Cu1100

  • Size/Color

  • customized

  • Surface  treatment

  • Sandblasting, Wire Drawing, Painting, Electroplating, Anodizing

  • Quality Control

  • full inspection

  • Application

  • Automobile、Source、Communication

  • OEM

  • Accept


  • Typ

  • Heatpipe Assembly Heat sink

  • Process

  • Bending/Flattening/Brazing

  • Extra Process

  • Extrusion/Skiving+CNC Machining

  • Material

  • Al1060、 Al 6061、Al6063、Cu1100、Cu1020

  • Size/Color

  • customized

  • Surface  treatment

  • Sandblasting, Wire Drawing, Painting, Electroplating, Anodizing

  • Quality Control

  • full inspection

  • Application

  • Mechanical Equipment、Source、Electronic Devices

  • OEM

  • Accept


Heat pipe is a type of heat transfer element, with a heat transfer efficiency that can reach several tens of times that of metal. It is composed of three main components: a sealed shell, working fluid, and capillary structure. The working fluid absorbs heat and vaporizes from the higher temperature side, while the saturated gas releases heat and condenses towards the lower temperature side. The working fluid changes phase within the application temperature range, and the casing keeps the working fluid of the heat pipe vacuum sealed to achieve continuous heat transfer for decades.


  • Type

  • Skived Fin Heat sink

  • Process

  • Skiving

  • Extra Process

  • Skiving+CNC Machining

  • Material

  • AL1060、AL 6061、AL6063、Cu1100、Cu1020

  • Size/Color

  • customized

  • Surface  treatment

  • Sandblasting, Wire Drawing, Painting, Electroplating, Anodizing

  • Quality Control

  • full inspection

  • Application

  • Automobile、Inverter、Communication

  • OEM

  • Accept


Skived fin heat sink is made of a piece of base material (aluminum or copper) .Under the mechanical action, the tilting Angle of the tool is controlled by the customized tool and the program written, the  base material  is precisely cut from the top by a shovel-tooth tool, and folded back to a position perpendicular to the base, and repeated at a certain spacing to form fins. Skived Fin Process can make the Fins thinner and denser, increasing the radiator area per unit volume, thereby improving heat dissipation efficiency.


ü The appearance of the heat sink should consider aesthetics and space utilization efficiency.

ü The internal flow channels of the heat sink should be as simple as possible to ensure smooth flow of the cooling medium.

ü Design the shape and size of the heat sink according to actual needs to increase the heat transfer area.

ü A reasonable support structure should be designed at the bottom of the heat sink to improve its stability and structural strength.


Extrusion molding is the process of applying external force to a metal ingot stored in a container (extrusion cylinder), causing it to flow out of a specific mold hole, in order to obtain the desired cross-sectional shape and size of the profile.


  • Type

  • Copper Tube cold plates

  • Process

  • buried pipe, welded pipe, double-sided clamp pipe

  • Extra Process

  • Brazing+CNC Machining

  • Material

  • AL 6061、AL6063、Cu1100

  • Size/Color

  • customized

  • Surface  treatment

  • Sandblasting, Wire Drawing, Painting, Electroplating, Anodizing

  • Quality Control

  • full inspection

  • Application

  • Automobile、Source、Communication

  • OEM

  • Accept


  • Typ

  • Heatpipe Assembly Heat sink

  • Process

  • Bending/Flattening/Brazing

  • Extra Process

  • Extrusion/Skiving+CNC Machining

  • Material

  • Al1060、 Al 6061、Al6063、Cu1100、Cu1020

  • Size/Color

  • customized

  • Surface  treatment

  • Sandblasting, Wire Drawing, Painting, Electroplating, Anodizing

  • Quality Control

  • full inspection

  • Application

  • Mechanical Equipment、Source、Electronic Devices

  • OEM

  • Accept


ü Good thermal conductivity

Strong thermal conductivity, relatively small thermal resistance, 100-1000 times that of copper pipes of the same size, reversible heat transfer direction, and can become the evaporation and condensation ends regardless of any end.

ü Wide application range

Suitable for a wide temperature range, from low temperature -243C to high temperature>1000C. And with a small temperature difference, it transports a large amount of heat.

ü High compatibility:

Simple and compact structure, light weight, small size, and easy maintenance. By using heat pipe technology, satisfactory heat dissipation can be achieved even without the need for fans or with low speed and low air volume motors, making it suitable for scenarios with high-power heat dissipation and low noise requirements. With the continuous improvement of heat pipe processing technology, its reliability, safety, and durability will be further improved, while the cost and price will also be further reduced.


  • Type

  • Skived Fin Heat sink

  • Process

  • Skiving

  • Extra Process

  • Skiving+CNC Machining

  • Material

  • AL1060、AL 6061、AL6063、Cu1100、Cu1020

  • Size/Color

  • customized

  • Surface  treatment

  • Sandblasting, Wire Drawing, Painting, Electroplating, Anodizing

  • Quality Control

  • full inspection

  • Application

  • Automobile、Inverter、Communication

  • OEM

  • Accept


ü Excellent thermal conductivity

The raw material for Skived fin heat sink is generally copper or aluminum, with a high thermal conductivity. The Skived Fin heat sink is constructed from a single piece of metal material, so the heat dissipation efficiency is not damaged.Without the limitation of the aspect ratio in mold manufacturing, the Fin can be produced thinner, longer, more dense.

ü Diversified structural types

Single sided,double-faced,special-shaped and four sided for pipes Skived heat sinks can be made for your needs.The current technology can meet the structural design requirements of the vast majority of heat sinks.

ü High durability

The surface of the Skived heat sinks adopt a special treatment process, which improves its strength and corrosion resistance. At the same time, there are gaps between the teeth, making the surface of the radiator less prone to curling.

ü  Light weighting

Compared to traditional heat sinks, a  Skived heat sink of the same quality can obtain a larger surface area, making the entire radiator lighter.


ü Good thermal conductivity

Six series aluminum profiles have good thermal conductivity, with a thermal conductivity coefficient between 120-165 W/(m · K); Integrated molding, with fins that do not require additional welding processing and no additional thermal resistance; The structure can be flexibly designed to improve the heat dissipation performance of the radiator.

ü High durability

The aluminum extruded heat sink is made of high-purity aluminum material and has undergone processes such as anodizing treatment on the surface, which can effectively prevent oxidation corrosion and loss, and has a long service life.

ü Lightweight

Aluminum extruded heat sink is lightweight and compact, making it more suitable for lightweight electronic products and mechanical equipment.


  • Type

  • Copper Tube cold plates

  • Process

  • buried pipe, welded pipe, double-sided clamp pipe

  • Extra Process

  • Brazing+CNC Machining

  • Material

  • AL 6061、AL6063、Cu1100

  • Size/Color

  • customized

  • Surface  treatment

  • Sandblasting, Wire Drawing, Painting, Electroplating, Anodizing

  • Quality Control

  • full inspection

  • Application

  • Automobile、Source、Communication

  • OEM

  • Accept


  • Typ

  • Heatpipe Assembly Heat sink

  • Process

  • Bending/Flattening/Brazing

  • Extra Process

  • Extrusion/Skiving+CNC Machining

  • Material

  • Al1060、 Al 6061、Al6063、Cu1100、Cu1020

  • Size/Color

  • customized

  • Surface  treatment

  • Sandblasting, Wire Drawing, Painting, Electroplating, Anodizing

  • Quality Control

  • full inspection

  • Application

  • Mechanical Equipment、Source、Electronic Devices

  • OEM

  • Accept


The heat transfer performance of heat pipes is indeed very powerful, but to better play its role, it still needs to rely on the precise matching of the basic modules, fins, and other components.

ü Heat pipe selection: Heat pipes with different capillary structures have certain differences in heat transfer performance. In practical applications, forming processes such as bending and flattening need to be carried out to meet the heat dissipation needs of different heat sources. In addition, the diameter, length, and assembly direction of heat pipes can also affect their heat transfer performance.

ü Heat sink production and assembly: usually paired with heat pipes, stamped and toothed heat sinks are used. The thickness, length, spacing, arrangement of heat sinks, connection process between Fin and heat pipes, penetration of Fin, reflow soldering, etc. all affect the overall heat dissipation performance.

ü Module welding: The substrate, heat pipe, and heat sink are finally combined by welding. The flatness of the substrate, the connection between Fin sheets and the substrate and heat pipe, and the welding between heat pipes and substrate will all generate additional thermal resistance.


  • Type

  • Skived Fin Heat sink

  • Process

  • Skiving

  • Extra Process

  • Skiving+CNC Machining

  • Material

  • AL1060、AL 6061、AL6063、Cu1100、Cu1020

  • Size/Color

  • customized

  • Surface  treatment

  • Sandblasting, Wire Drawing, Painting, Electroplating, Anodizing

  • Quality Control

  • full inspection

  • Application

  • Automobile、Inverter、Communication

  • OEM

  • Accept


ü  Fin design considerations:  Overall consideration should be given to heat exchange area, wind speed, heat exchange efficiency, Fin sheets that are too thin are prone to deformation, while those that are too dense can affect heat dissipation.

ü Determine the size of the heat sink based on usage and heat dissipation needs. The internal flow channels of the radiator should be as simple as possible to ensure smooth flow of the cooling medium.


  • Type

  • Copper Tube cold plates

  • Process

  • buried pipe, welded pipe, double-sided clamp pipe

  • Extra Process

  • Brazing+CNC Machining

  • Material

  • AL 6061、AL6063、Cu1100

  • Size/Color

  • customized

  • Surface  treatment

  • Sandblasting, Wire Drawing, Painting, Electroplating, Anodizing

  • Quality Control

  • full inspection

  • Application

  • Automobile、Source、Communication

  • OEM

  • Accept


  • Typ

  • Heatpipe Assembly Heat sink

  • Process

  • Bending/Flattening/Brazing

  • Extra Process

  • Extrusion/Skiving+CNC Machining

  • Material

  • Al1060、 Al 6061、Al6063、Cu1100、Cu1020

  • Size/Color

  • customized

  • Surface  treatment

  • Sandblasting, Wire Drawing, Painting, Electroplating, Anodizing

  • Quality Control

  • full inspection

  • Application

  • Mechanical Equipment、Source、Electronic Devices

  • OEM

  • Accept


ü High power heat dissipation requirements, ideal choice for limited space, low noise, and environmentally friendly scenarios.

ü The engineering decision for the best solution for heat sinks generally depends on cost and performance. Heat pipe module heat sinks can be assembled and welded from heat pipes of different structures, Fin sheets of different processes, and substrates of different materials. Therefore, under the constraints of different application scenarios and working conditions, the cost range of a single heat dissipation module is very wide.

 ü Walmate ready to provide professional and more economical opinions based on your specific application scenario and demand scale.






  • Type

  • Skived Fin Heat sink

  • Process

  • Skiving

  • Extra Process

  • Skiving+CNC Machining

  • Material

  • AL1060、AL 6061、AL6063、Cu1100、Cu1020

  • Size/Color

  • customized

  • Surface  treatment

  • Sandblasting, Wire Drawing, Painting, Electroplating, Anodizing

  • Quality Control

  • full inspection

  • Application

  • Automobile、Inverter、Communication

  • OEM

  • Accept


ü There is no need for additional forming molds during the tooth removal process, so for different product sizes and structures, only materials and blades need to be replaced, and a new tooth removal program needs to be set.

ü Choosing the Skived Fin Process to make samples can significantly shorten the sampling time and cost.

ü  The Skived Fin heat sinks can be equipped with a heat pipe, which has significant economic benefits in high-power heat dissipation scenarios.

ü  Walmate ready to provide professional and more economical opinions based on your specific application scenario and demand scale.


ü Extrusion is the most operational and cost-effective process for producing plate fins and cross cut heat sink.

ü The six series aluminum material used for extrusion has good mechanical properties and superior thermal conductivity.

ü The tooling and unit price are the lowest among all large-scale production processes.

ü Walmate ready to provide professional and more economical opinions based on your specific application scenario and demand scale.
